HFSS 11 最新設計實例培訓教材

英文原版 PDF格式 547頁

購買套裝 免費贈送

            Ansoft最新版HFSS11設計實例內部原版培訓教程，通過實例操作一步步講解HFSS11的實際應用；主要內容如下：
    Introduction
    Chapter 5.0 – Antenna Examples
        5.1 – UHF Probe
        5.2 – Circular Waveguide Horn
        5.3 – Probe Feed Patch
        5.4 – Slot Coupled Patch
        5.5 – Endfire Array
    Chapter 6.0 – Microwave Examples
        6.1 – Magic T
        6.2 – Coax Bend
        6.3 – Ring Hybrid
        6.4 – Coax Stub: Includes Optimetrics Example
        6.5 – Microstrip - Wave Ports: Includes Optimetrics Example
    Chapter 7.0 – Filter Examples
        7.1 – Bandpass Filter
    Chapter 8.0 – Signal Integrity Examples
        8.1a – LVDS Differential Pair: Includes Optimetrics Example
        8.1b – LVDS Differential Pair Transient Simulation (Ansoft Designer)
        8.2a – Segmented Return Path
        8.2b – Segmented Return Path TDR (Ansoft Designer)
        8.3 – Non-Ideal Planes
        8.4 – Return Path
    Chapter 9.0 – On Chip Component Examples
        9.1 – Spiral Inductor
